Description
Onyx TX7 Propane Planetary Stripping Machine, 27 in, 708cc
TX7 is the ultimate, all-in-one, stripper, burnisher, grinder, and polisher. Featuring a heavy duty timing belt driven planetary with three 10" counter rotating heads, the TX7 aggressively strips multiple coats of floor finish with one pass with zero torque on the operator. Easily swap the heads to pad drivers or diamond drivers to burnish or grind and polish vct, terrazzo, and concrete floors. An on-board 8 gallon water tank makes the TX7 a totally cordless machine perfect from small concrete patchwork to large square footage strip and polish jobs.
FAST • CLEAN • RELIABLE
Strip up to 10,000 sq ft per hour | Ultra Low noise level | Industry Leading Power
FAST
- Strip up to 10,000 sq ft per hour
- Tool-less easy pad removal
- Headlight illuminates working area
- On-board water system boosts productivity
- 27” Three disc planetary design eliminates torque on the operator for exceptional ease of use
RELIABLE
- Heavy duty steel frame construction
- Industrial grade high temp bearings
- Industrial grade drive shaft
CLEAN
- Qualifies for Near zero emission (NZE) contract bids
- Certified 100x below EPA Carbon Monoxide stds
- Lowest carbon emissions in its class, by 53%
- Floating brush skirt contains dust
- Ultra Low noise level
- Anti-vibration design
- On-board real-time emissions monitoring with SAM Safe Air Monitor
FACILITIES / USE CASES
- Construction contractors
- Industrial / Manufacturing
- Grocery
- Big Box Retail / Warehouses
- Airports
- Schools / Education
- Rental
Specifications
| Product Function | Floor Stripping |
| Operation Mode | Walk-Behind Pad Assist |
| Power | LX700 20hp Propane Engine |
| Working Width | 27" |
| Run Time | 6 Hours Per 20lb Propane Cylinder |
| Pad / Brush Size | 10" |
| Weight | 450 lbs |
| Pad Speed | 540-1080 RPM |
TECHNICAL SPECIFICATIONS
- Working Width 27” w/ HDPE Splash Guard Floating Skirt
- Performance Up to 10,000 Sq Ft Per Hour
- Engine 708cc 19 HP, LPG Fuel System, EPA Certified
- Sound Level 87 dBA
- Brush/Pad Speed 540-1080 RPM
- Brush/Pad Size 3 - 10” Drivers/Brushes
- Run Time 6 Hours Per 20lb Cylinder
- Frame Powder Coated Reinforced Steel
- Dimensions 30”W x 53”L x 40-48”H adjustable
- Weight 450 lbs, Shipping Weight 480lbs
- Ignition System 12v Electric Start
- Fuel Tank 20lb Steel with Overfill Protection Device Installed
- Warranty 3 Years Engine and Frame; 1 Year Components; 90 Days Wearable Parts
- Water Tank 8 Gallon Gravity Feed Water System
